Microscope

XJE300

Your position ：Home >Microscope >Biological Microscope >XJE >XJE300

XJE300

Superior imaging quality than expected for teaching experiments, pathological analysis and clinical diagnosis. Infrared intelligent sensing system can be configured to save energy and protect the environment.

1． Introduction

The biological microscope specially designed for universitis or laboratories of biomedicine,and other relevant institutions.Train of thought in the design, made a comprehensive innovation and broke with the traditional design style.Its outstanding functions,excellent cost performance,easy and comfortable operation,presents an over expected splendid micro image.

2． Image


Specification		XJE300B	XJE300T
Optical System	Infinity corrected Achromatic optical system	●	●
Viewing Head	Siedentopf Binocular, Inclined at 30 °, Rotatable 360°, Interpupilary Distance: 50~75mm	●
	Siedentopf Trinocular, Inclined at 30 ° , Rotatable 360°, Interpupilary Distance: 50~75mm, Light Distribution: 20/80 (If fluorescence, it is 50/50)		●
	30°gemel trinocular viewing head(dedicated for fluorescence) with 360° rotatable eyepiece tube, interpupillary adjustable distance: 50-75mm, fixed spectroscopical ratio R:T= 50%:50%
	30°gemel digital viewing head(with 3.0/5.0 mega pixels)
Eyepiece	PL10X/20T High eye-point wide-field plan eyepiece, field of view: 20mm,effective exit pupil distance: 19mm, diopter +/-5 adjustable	●	●
	PL10X/22T High eye-point wide-field plan eyepiece, field of view: 20mm, effective exit pupil distance: 19mm, diopter +/-5 adjustable
	Plan Achromatic 2X/0.06
	Plan Achromatic 4X/0.10	●	●
	Plan Achromatic 10X/0.25	●	●
	Plan Achromatic 20X/0.50
	Plan Achromatic 40X/0.65(S)	●	●
	Plan Achromatic 100X/1.25(Oil,S)	●	●
Polarization	Simply Polarizer
Nosepiece	Reversed quadruple nosepiece	●	●
Nosepiece	Reversed quintuple nosepiece
Objective	Plan Phase Contrast 10X/0.25 WD=4.7
	Plan Phase Contrast 20X/0.50 WD=1.75
	Plan Phase Contrast 40X/0.65 WD=0.72
	Plan Phase Contrast 100X/1.25 WD=0.15
	Plan Semi-Apo Fluoresence 4X/0.13 WD=15.3
	Plan Semi-Apo Fluoresence 10X/0.30 WD=8.7
	Plan Semi-Apo Fluoresence 20X/0.50 WD=2.5
	Plan Semi-Apo Fluoresence 40X/0.75 WD=0.72
	Plan Semi-Apo Fluoresence 100X/1.3 WD=0.21
Stage	Double Stage: 150×140mm Moving Range: 76×50mm precision: 0.1mm, with damping clips	●	●
Condenser	N.A.1.25 Koehler illuminator condenser(with socket for phase contrast and dark-field accessories)	●	●
Filter	Blue(45mm)
	Green(45mm)
	Neutral(45mm)
Illumination	Reflected: Mercury reflected fluorescent illuminator, 100W mercury lamp house, 100W DC mercury bulb(OSRAM/domestic)
	Transmitted: 100V-240V_AC50/60Hz wide range voltage, single high brightness 3W LED(predetermine filament center), intensity continuously adjustable.	●	●
	100V-240V_AC50/60Hz wide range voltage, Philips 6V/30W halogen bulbs(predetermined filament center), intensity continuously adjustable
C-mount	1X
	0.5X
	0.35
Optional Accessories	Fluoresence Attaches(B, G)
	Fluoresence Attaches(UV, V)
	LED Fluoresence Attaches(365mm)
	LED Fluoresence Attaches(455mm)
	LED Fluoresence Attaches(470mm)
	LED Fluoresence Attaches(560mm)
	Fluoresence Attaches(B, G)
	Fluoresence Attaches(UV, V)
Volume and Weight	57.155.427.8CM 11KGS

Note: "●"In Table Is Standard outfits,"○" Is Optional Accessories.
